MongoDB ERD CLI

MongoDB ERD CLI

A powerful command-line tool for generating Entity-Relationship Diagrams from MongoDB databases, with support for multiple output formats and relationship detection

By Michael Lynn • 4/10/2024
Share this article:

MongoDB ERD CLI

Generating Entity-Relationship Diagrams (ERD) for MongoDB databases has traditionally been a manual and time-consuming process. The MongoDB ERD CLI tool solves this challenge by automatically analyzing your database structure and generating visual diagrams directly from the command line.

Project Overview

MongoDB ERD CLI is a command-line interface tool that extends the functionality of my web-based ERD generator into a standalone utility. It's designed for developers who need to generate database documentation as part of their CI/CD pipelines, local development workflows, or automation scripts.
title="MongoDB  chart={`
flowchart TD
    CLI([CLI Input]) --> Config[Configuration Parser]
    Config --> DBConnect[MongoDB Connection]
    DBConnect --> Introspect[Schema Introspector]
    Introspect --> RelDetect[Relationship Detector]
    RelDetect --> Generator[Diagram Generator]
    Generator --> Output[File Output]

    subgraph Analysis
    Introspect
    RelDetect
    end

    subgraph Generation
    Generator
    Output
    end

    classDef primary fill:#00ED64,stroke:#00C853,color:black;
    classDef secondary fill:#2196F3,stroke:#1976D2,color:white;
    classDef tertiary fill:#FFC107,stroke:#FFA000,color:black;

    class CLI,Config primary;
    class DBConnect,Introspect,RelDetect secondary;
    class Generator,Output tertiary;
  `}
  caption="High-level architecture of the MongoDB ERD CLI tool"
/>

## ✨ Key Features

- 🔍 **Database Analysis**: Connect to MongoDB databases and analyze collection structures
- 🔗 **Relationship Detection**: Automatically identify relationships between collections
- 📊 **ERD Generation**: Generate Mermaid ERD diagrams with proper relationships
- 🎨 **Multiple Formats**: Support for SVG, PNG, PDF, ASCII, and Mermaid syntax
- 🎯 **Customization**: Flexible theme and styling options
- 🔄 **Collection Filtering**: Include or exclude specific collections
- 🚀 **Easy Installation**: Available as an NPM package
- 🔒 **Secure**: Handles connection strings and credentials safely

## 💻 Usage Guide

### Installation

```bash
npm install -g mongodb-erd-cli

Basic Usage

bashmongodb-erd --uri "mongodb://localhost:27017" --database "my_database" --output "diagram.svg"

Advanced Options

bashmongodb-erd \\
  --uri "mongodb+srv://..." \\
  --database "blog" \\
  --output "blog-erd.png" \\
  --format png \\
  --theme dark \\
  --include "posts,users,comments"

Configuration Options

| Option | Description | Required | Default | |--------|-------------|----------|---------| | --uri | MongoDB connection URI | Yes | - | | --database | Database name | Yes | - | | --output | Output file path | Yes | - | | --format | Output format (svg, png, pdf) | No | "svg" | | --theme | Diagram theme (default, dark) | No | "default" | | --include | Comma-separated list of collections to include | No | - | | --exclude | Comma-separated list of collections to exclude | No | - |

Technical Implementation

The project is built with modern Node.js technologies and follows best practices for CLI tool development.

Tech Stack

Node.js
MongoDB Driver
Commander.js
Mermaid.js
html-to-image

Core Components

The system consists of several key modules working together:

Core Components


classDiagram
    class CLI {
        +parseArgs()
        +validateConfig()
        +execute()
    }
    class DBIntrospector {
        +connect()
        +analyzeCollections()
        +detectRelationships()
    }
    class DiagramGenerator {
        +generateMermaid()
        +convertFormat()
        +saveOutput()
    }
    class ConfigManager {
        +loadEnv()
        +validateUri()
        +mergeOptions()
    }

    CLI --> ConfigManager
    CLI --> DBIntrospector
    CLI --> DiagramGenerator
    DBIntrospector --> DiagramGenerator
Core components and their relationships

Database Analysis

The tool uses sophisticated algorithms to analyze database structure:

flowchart LR
    subgraph "Collection Analysis"
    A[Sample Documents] --> B[Extract Schema]
    B --> C[Detect Types]
    C --> D[Find References]
    end

    subgraph "Relationship Detection"
    D --> E{Is ObjectId?}
    E -->|Yes| F[Check Target]
    E -->|No| G{Name Pattern?}
    G -->|Yes| F
    G -->|No| H{Array Ref?}
    H --> F
    F --> I[Create Relation]
    end

    style A fill:#bbdefb
    style B fill:#bbdefb
    style C fill:#bbdefb
    style D fill:#c8e6c9
    style E fill:#fff9c4
    style F fill:#fff9c4
    style G fill:#fff9c4
    style H fill:#fff9c4
    style I fill:#ffccbc
Database analysis and relationship detection flow

Development Process

The development followed a structured approach:

gantt
    title Development Timeline
    dateFormat  YYYY-MM-DD
    section Core
    CLI Framework     :a1, 2024-03-01, 7d
    DB Introspection  :a2, after a1, 7d
    section Features
    ERD Generation    :a3, after a2, 7d
    Output Formats    :a4, after a3, 5d
    section Polish
    Documentation     :a5, after a4, 5d
    Testing          :a6, after a4, 5d
    section Release
    NPM Package      :a7, after a5, 3d
Project development timeline

Challenges and Solutions

Challenge 1: Relationship Detection

Detecting relationships in MongoDB's flexible schema presented unique challenges.
Solution: Implemented multiple detection strategies:
  • ObjectId reference detection
  • Field name pattern matching
  • Array reference analysis
  • Nested document structure analysis

Challenge 2: Output Format Handling

Converting Mermaid diagrams to various formats required careful handling.
Solution: Created a modular output system that:
  • Generates clean Mermaid syntax
  • Uses puppeteer for PNG/PDF conversion
  • Implements proper error handling
  • Supports custom themes

Challenge 3: CLI User Experience

Creating an intuitive CLI experience while handling complex options.
Solution:
  • Implemented Commander.js for argument parsing
  • Added environment variable support
  • Created clear error messages
  • Provided sensible defaults

Future Enhancements

Several exciting features are planned:
  1. Interactive Mode: CLI wizard for configuration
  2. Custom Templates: User-defined diagram templates
  3. Batch Processing: Multiple database support
  4. Schema Versioning: Track schema changes over time
  5. Cloud Integration: Direct integration with MongoDB Atlas
  6. Plugin System: Extensible architecture for custom features

Conclusion

The MongoDB ERD CLI tool demonstrates how automation can simplify database documentation. By combining MongoDB's powerful driver with modern CLI design patterns, it provides a seamless experience for generating database diagrams.
Try it yourself:
bashnpm install -g mongodb-erd-cli
Or use the web version for a graphical interface.

🛠️ Development

Want to contribute? Here's how to get started:
  1. Clone the repository:
bashgit clone https://github.com/mlynn/mongodb-erd-cli.git
cd mongodb-erd-cli
  1. Install dependencies:
bashnpm install
  1. Run tests:
bashnpm test
  1. Run linting:
bashnpm run lint

🤝 Contributing

  1. Fork the repository
  2. Create your feature branch (git checkout -b feature/amazing-feature)
  3. Commit your changes (git commit -m 'Add some amazing feature')
  4. Push to the branch (git push origin feature/amazing-feature)
  5. Open a Pull Request

📄 License

This project is licensed under the MIT License - see the LICENSE file for details.
